High brightness china good quality full color transparent led flexible curtain display board for window shopping mall.
1.CCC,CE&Rohs,ISO9001,FC,
2.Life span:more than 100000h
3.Excellent after-sales services with free repaire whole life
4.MOQ: 1pcs
5.Prompt delivery: 10 working days after get deposit.
Transparent LED display application:Especially suitable for shopping malls , specialty stores ,exhibithions ,
banks ,resturant chains , medical beauty , clothing stores and other high-end places for advertising, it's very beautiful and easy to install , do not occupy the position.
Because of its strip shape, hollowing, light transmission, and does not affect the ventilation
and lighting of the product form, it is commonly known in the industry as LED transparent screen,
LED through screen, LED hollow screen, LED glass screen, LED grill screen and so on.
Detailed specification as follows.
| Pixel Pitch | P3.91-7.81mm |
| LED Resources | SMD2121NL copper cable |
| Display Resolution/Cabinet | 252*64 dots ( WXH) |
| Net Weight/Cabinet | 9kg |
| Working Voltage | AC220V |
| Min. viewing distance | 4m |
| Max Power consumption/Modules | ≤14W |
| Driving Method | 1/16 duty |
| White Balance Brightness | ≥1000 nits |
| Viewing Angle( H/V ) | 140/140 ° |
| Transparent rate | ≥70% |
| Frame Changing Rate | 60fps |
| Grey Levels | 16 bits Hz |
| Refresh | ≥3840 |
| Lifetime | ≥50000 hours |
| Working Temp. | -15~+45 ℃ |
| Working Humidity | 10%-80%RH |
| Storage Temp. | -20~+60 ℃ |
| Storage Humidity | 10%-80%RH |
1. Different batch or different company's led module ,
they can't be used together because the color ,brightness,signal direction of PCB board are different.
(Different batch screw holes position on the housing might be diferent with the picture, pls confirm with us before order).
2.As thest products easy to broken, we suggest you choose express(DHL,Fedex, UPS, TNT) shipping ensure folwless and prefect.
3. All the series modules are 5V power ,make sure your switch power supply suitalbe.
4. We will choose the conveninet shipping method ensure you get products earlier.
